• 2×10 Floor Joists @ 16″ O.C. with Double Perimeter Band – Front and Rear
• 3/4″ T&G OSB Floor Decking Glued and Nailed
• 8′-0″ Wall Height
• 2×6 Exterior Walls @ 16″ O.C. with 7/16″ OSB Sheathing
• Double 2x4 Mating Walls @ 16" O.C. with Sheathing
• Double 2×4 Mating Walls @ 16″ O.C.
• 2×4 Interior Walls @ 16″ O.C.
• 7/12 Pitch, Non-Storage Rafter Roof System @ 16″ O.C.
• 10″ Eave Overhangs, Fixed When Possible
• 10″ Gable End Overhangs
• 7/16″ OSB Roof Sheathing

• R-38 Ceiling Insulation with Vapor Barrier
• R-21 Fiberglass Exterior Wall Insulation with Vapor Barrier
• Exterior House Wrap

• Tuff-Pex Fresh Water Lines Stubbed (Code Dictates)
• PVC Drain, Waste and Vents (Stubbed)
• Shut-Off Valves on All Fixtures

• 200 AMP Main Service Panel
• Smoke Detectors and Carbon Monoxide Detectors (Per Code)
• Two RG-6 TV Jacks and Two Cat-5e Phone Jacks
• Wired Door Chimes (One in Front and One in Rear)
• One USB In-Wall Charger (Receptacle)
• Brushed Nickel Ceiling Lights in Bedroom, Hall, Laundry, Kitchen, Dining Room, Foyer, and Walk-In Closets
• Recessed Can Light Over Kitchen Sink with Separate Switch
• Two Pendant Lights Above Kitchen Islands and Peninsulas (Per Plan)
• Fan/Light Combination in All Bathrooms
• One Exterior Light Supplied for Each Exterior Door (Per Plan)
• One Exterior GFCI Receptacle Supplied for Each Exterior Door

‍

• CertainTeed® Architectural Shingles
• Ice Shield Installed on Eave Overhangs
• Minimum 15# Felt Paper Shingle Underlayment
• Vented Vinyl Soffit, Ribbed Aluminum Fascia, and Aluminum Drip Edge
• Shingle Over Ridge Vent (Shipped Loose)
• CertainTeed® MainStreet™ Vinyl Siding (Double 4 Clapboard, Double 5 Clapboard, or Dutch Lap)
• Smooth Fiberglass Front Door with 2-Panel Square, Composite Jambs, and Vinyl Brickmould (Per Plan)
• Smooth Fiberglass Front Door with Sunburst, Composite Jambs, and Vinyl Brickmould (Per Plan)
• Smooth Fiberglass Rear Door with Half Glass, Composite Jambs, and Vinyl Brickmould (Per Plan)
• Satin Nickel Schlage® Keyless Touchscreen Deadbolt with Lever – Exterior Door Hardware (Per Plan)
• 6′-0″ Vinyl Sliding Glass Door (Per Plan)
• Exterior Swing Doors Installed with Pan and Bracing Beneath Jamb
• Vinyl Double Hung Low-E Brickmould Windows with Screens and Argon Gas
• Vinyl Shutters, Installed on Front (Per Plan)

‍

• None

• Oak Recessed Flat Panel Kitchen Cabinets, Traditional Overlay
• Wall Cabinets with 3/4″ Shelving, 2-1/2″ Crown Moulding and Under Cabinet Trim
• Base Cabinets with One Pull-Out Tray (Over 12″ Deep Only) and Dove Trail Drawers with 75 lb. Full Extension Drawer Glides with Soft-Action Close Mechanism
• Elevated Corner Wall Cabinet, Crown and Under Cabinet Trim (Per Plan)
• High Pressure, Square Edge Laminate Top with Backsplash
• 8″ Deep, Double Bowl Stainless Steel Sink and Gooseneck Faucet with Pull-Down Spray
• Wired for On-Site Electric Range (Per Plan)
• 30″ Kitchen Range Hood (Vented to Exterior)
• Ice Maker Hook-Up (Recessed Box for On-Site Appliance)

• Oak Recessed Flat Panel Bath Cabinets, Traditional Overlay
• One-Piece Cultured Marble Vanity Top
• Medicine Cabinet with Mirror and Decorative Lighting (Per Vanity Bowl)
• 60″ One-Piece Fiberglass Tub/Shower with Anti-Scald Valves
• Elongated Water Saver Water Closets
• Moen® Brushed Nickel Faucets in Bathrooms
• 2-in-1 Shower Hand Spray in Master Bathroom

• All Icon Legacy Custom Modular Homes, LLC’s Modular Structures Come with a 10-Year Structural Warranty
